ORIGINAL ARTICLE
Sweet pepper foliar diseases quantification and identification using an image analysis tool
1
Department of Computing and Information Technology, Faculty of Science and Technology, The University of the West Indies
St. Augustine Campus, Trinidad and Tobago
2
Department of Life Science, Faculty of Science and Technology, The University of the West Indies, St. Augustine Campus,
Trinidad and Tobago
A - Research concept and design; B - Collection and/or assembly of data; C - Data analysis and interpretation; D - Writing the article; E - Critical revision of the article; F - Final approval of article
Submission date: 2024-04-25
Acceptance date: 2024-07-25
Online publication date: 2025-03-25
Corresponding author
Vijayanadh Rajamanickam
Department of Computing and Information Technology, Faculty of Science and Technology, The University of the West Indies St. Augustine Campus, Trinidad and Tobago
Department of Computing and Information Technology, Faculty of Science and Technology, The University of the West Indies St. Augustine Campus, Trinidad and Tobago
HIGHLIGHTS
- Images captured by smartphones were used in digital tools.
- The farmer or user can get the results very quickly with the use of digital tools.
- Digital tools for quantifying & identifying diseases of sweet pepper foliar diseases
- Thresholding and texture-based disease detection
- GLCM Texture features have been extracted and classified by various ML classifiers
KEYWORDS
TOPICS
ABSTRACT
Quantification and assessment of disease symptoms are important elements of plant disease
management systems and are required to assist with making decisions on the choice
of protective agents to be applied to crops or for screening plant genotypes for the development
of resistant varieties. Traditional methods of identifying and quantifying disease
severity are cumbersome, involving visual assessment tools or scales, and rating of plants at
a point in time. Visual assessment is prone to human bias and error, thereby reducing the
efficiency and accuracy of this method. In this study, we developed a smartphone camera-
-based image recording, processing, and assessment tool for measurement of symptoms of
early and late blight, and bacterial leaf spot diseases in sweet pepper caused by Alternaria
solani, Phytophthora infestans, and Xanthomonas campestris pv. vesicatoria, respectively.
Sweet pepper or bell pepper is a major vegetable crop grown in the Caribbean region, but
production is severely affected by plant diseases, most important of which include foliar
infections by fungi and bacteria that cause major losses in fruit yield. This research utilized
smartphone captured images of leaf specimens for severity measurement and classification
of diseases. The steps involved were color space conversions, detection of leaf area by Otsu’s
method, and thresholding for foliar diseased area detection and quantification. Gray-Level
Co-occurrence Matrix (GLCM) extracted the texture features from the diseased area of
leaves. These features are trained and classified by various machine learning classifiers including
trees, rule-based and Bayes models. Application of decision trees and rule-based
classifier models achieved 98% accuracy individually, while Bayes model achieved 86% accuracy.
The image input into the above classifier models resulted in fast and accurate identification
of the diseases by matching the features of trained images of disease symptoms.
This method could work well for leaves collected from field-grown plants as well as from
inoculated greenhouse plants.
ACKNOWLEDGEMENTS
We wish to thank the Campus Research and Publication
Fund Committee, The University of the West Indies,
St. Augustine Campus, Trinidad and Tobago for
funding this study and the farmers of Macoya, Orange
Grove and Aranguez for their assistance in the collection
of plant samples.
RESPONSIBLE EDITOR
Piotr Iwaniuk
CONFLICT OF INTEREST
The authors have declared that no conflict of interests exist.
REFERENCES (46)
1.
Akay R., Saleh R.A.A., Farea S.M.O., Kanaan M. 2022. Multilevel thresholding segmentation of color plant disease images using metaheuristic optimization algorithms. Neural Computing and Applications 34: 1161–1179. DOI: https://doi.org/10.1007/s00521....
2.
Alheeti A.A. M., Farhan M.A., Al-Saad L.A., Theer R.M. 2021. IOP Conference Series: Earth and Environmental Science 761 012030. DOI: 10.1088/1755-1315/761/1/012030.
3.
Ali O., Ramsubhag A., Jayaraj J. 2019. Biostimulatory activities of Ascophyllum nodosum extract in tomato and sweet pepper crops in a tropical environment. PLOS ONE 14 (5): e0216710. DOI: https://doi.org/10.1371/journa....
4.
Anjna, Sood M., Singh P.K. 2020. Hybrid System for Detection and Classification of Plant Disease Using Qualitative Texture Features Analysis. Procedia Computer Science 167: 1056-1065. DOI: https://doi.org/10.1016/j.proc....
5.
Applalanaidu M.V., Kumaravelan G. 2021. A review of machine learning approaches in plant leaf disease detection and classification. p. 716-724. In: Proceedings of the Third International Conference on Intelligent Communication Technologies and Virtual Mobile Networks (ICICV). 4-6 February 2021, Tirunelveli, India. DOI: 10.1109/ICICV50876.2021.9388488.
6.
Barbedo J.G.A. 2016. A review on the main challenges in automatic plant disease identification based on visible range images. Biosystems Engineering 144: 52-60. DOI: https://doi.org/10.1016/j.bios....
7.
Bezabh Y.A., Salau A.O., Abuhayi B.M., Mussa A.A., Ayalew A.M. 2023. CPD-CCNN: classification of pepper disease using a concatenation of convolutional neural network models. Scientific Reports 13: 15581. DOI: https://doi.org/10.1038/s41598....
8.
Bhagat M., Kumar D., Kumar S. 2023. Bell pepper leaf disease classification with LBP and VGG-16 based fused features and RF classifier. International Journal of Information Technology 15: 465–475. DOI: https://doi.org/10.1007/s41870....
9.
Bock C.H., Chiang K.S., Del Ponte E.M. 2022. Plant disease severity estimated visually: a century of research, best practices, and opportunities for improving methods and practices to maximize accuracy. Tropical Plant Pathology 47: 25–42. DOI: https://doi.org/10.1007/s40858....
10.
Chakole S.S., Khera S., Ukani N.A. 2022. Analysis of plant leaf disease based on sensor and machine learning technique. p. 1-4. In: Proceedings of the IEEE International Conference on Current Development in Engineering and Technology (CCET). 23-24 December 2022, Bhopal, India. DOI: 10.1109/CCET56606.2022.10080352.
11.
Chinnadurai C., Ramkissoon A., Rajendran R., Ramsubhag A., Jayaraj J. 2018. Disease status of tomatoes in the Southern Caribbean. Tropical Agriculture 95: 29-35.
12.
Das P.K. 2023. Leaf disease classification in bell pepper plant using VGGNet. Journal of Innovative Image Processing 5 (1): 36-46. DOI: 10.36548/jiip.2023.1.003.
13.
Das S., Pattanayak S., Behera P.R. 2022. Application of machine learning: a recent advancement in plant diseases detection. Journal of Plant Protection Research 62 (2): 122-135. DOI: https://doi.org/10.24425/jppr.....
14.
Davis J., Goadrich M. 2006. The relationship between Precision-Recall and ROC curves. p. 233–240. In: Proceedings of the 23rd International Conference on Machine Learning (ICML ‘06). Association for Computing Machinery, New York, NY, USA. DOI: https://doi.org/10.1145/114384....
15.
Francisco M., Ribeiro F., Metrôlho J., Dionísio R. 2023. Algorithms and models for automatic detection and classification of diseases and pests in agricultural crops: A systematic review. Applied Sciences 13 (8): 4720. DOI: https://doi.org/10.3390/app130....
16.
Hasanaliyeva G., Si Ammour M., Yaseen T., Rossi V., Caffi T. 2022. Innovations in disease detection and forecasting: A digital roadmap for sustainable management of fruit and foliar disease. Agronomy 12: 1707. DOI: https://doi.org/10.3390/agrono....
17.
Hassan S.M., Amitab K., Jasinski M., Leonowicz Z., Jasinska E., Novak T., Maji A.K. 2022. A survey on different plant diseases detection using machine learning techniques. Electronics 11: 2641. DOI: https://doi.org/10.3390/electr....
18.
Kotsiantis S.B. 2007. Supervised machine learning: A review of classification techniques. Informatica 31: 249-268.
19.
Kulmaganbetov M., Bevan R.J., Anantrasirichai N., Achim A., Erchova I., White N., Albon J., Morgan J.E. 2022. Textural feature analysis of optical coherence tomography phantoms. Electronics 11 (4): 669. DOI: https://doi.org/10.3390/electr....
20.
Li C., Adhikari R., Yao Y., Miller A.G., Kalbaugh K., Li D., Nemali K. 2020. Measuring plant growth characteristics using smartphone based image analysis technique in controlled environment agriculture. Computers and Electronics in Agriculture 168: 105123. DOI: https://doi.org/10.1016/j.comp....
21.
Mall P.K., Singh P.K., Yadav D. 2019. GLCM based feature extraction and medical x-ray image classification using machine learning techniques. p. 1-6. In: Proceedings of the IEEE Conference on Information and Communication Technology. 6-8 December 2019, Allahabad, India. DOI: 10.1109/CICT48419.2019.9066263.
22.
Naegele R.P., Granke L.L., Fry J., Hill T.A., Ashrafi H., Van Deynze A., Hausbeck M.K. 2017. Disease resistance to multiple fungal and oomycete pathogens evaluated using a recombinant inbred line population in pepper. Phytopathology 107 (12): 1522-1531. DOI: https://doi.org/10.1094/PHYTO-....
23.
Nyarko B.N.E., Bin W., Jinzhi Z., Odoom J. 2023. Tomato fruit disease detection based on improved single shot detection algorithm. Journal of Plant Protection Research 63 (4): 405-417. DOI: https://doi.org/10.24425/jppr.....
24.
Otsu N. 1979. A threshold selection method from gray-level histograms. p. 62-66. In: Proceedings of the IEEE Transactions on Systems, Man, and Cybernetics 9 (1). DOI: 10.1109/TSMC.1979.4310076.
25.
Priyanka, Kumar D. 2020. Feature extraction and selection of kidney ultrasound images using GLCM and PCA. Procedia Computer Science 167: 1722-1731. DOI: https://doi.org/10.1016/j.proc....
26.
Puspha Annabel L.S., Annapoorani T., Deepalakshmi P. 2019. Machine learning for plant leaf disease detection and classification – A review. p. 0538-0542. In: Proceedings of the International Conference on Communication and Signal Processing (ICCSP). 4-6 April 2019, Chennai, India. DOI: 10.1109/ICCSP.2019.8698004.
27.
Ramesh G., Albert W., Ramu G. 2020. Detection of plant diseases by analyzing the texture of leaf using ANN classifier. International Journal of Advanced Science and Technology 29 (8): 1656-1664.
28.
Ramsubhag A., Jayaraj J. 2018. Review paper rapid molecular methods for plant disease diagnosis. Tropical Agriculture 95: 166-177.
29.
Rani S., Das K., Aminuzzaman F., Ayim B.Y., Borodynko-Filas N. 2023. Harnessing the future: cutting-edge technologies for plant disease control. Journal of Plant Protection Research 63 (4): 387-398. DOI: https://doi.org/10.24425/jppr.....
30.
Saleem M.H., Potgieter J., Arif K.M. 2019. Plant disease detection and classification by deep learning. Plants 8 (11): 468. DOI: https://doi.org/10.3390/plants....
31.
Sapkal A.T., Kulkarni U.V. 2018. Comparative study of leaf disease diagnosis system using texture features and deep learning features. International Journal of Applied Engineering Research 13 (19): 14334-14340.
32.
Sarker I.H., Kayes A.S.M., Watters P. 2019. Effectiveness analysis of machine learning classification models for predicting personalized context-aware smartphone usage. Journal of Big Data 6: 57. DOI: https://doi.org/10.1186/s40537....
33.
Schroeder A.B., Dobson E.T.A., Rueden C.T., Tomancak P., Jug F., Eliceiri K.W. 2021. The ImageJ ecosystem: Open-source software for image visualization, processing, and analysis. Protein Science 30: 234–249. DOI: https://doi.org/10.1002/pro.39....
34.
Shafique H., Viqar S., Ehteshamul-Haque S., Athar M. 2016. Management of soil-borne diseases of organic vegetables. Journal of Plant Protection Research 56 (3): 221–230. DOI: 10.1515/jppr-2016-0043.
35.
Shi T., Liu Y., Zheng X., Hu K., Huang H., Liu H., Huang H. 2023. Recent advances in plant disease severity assessment using convolutional neural networks. Scientific Reports 13: 2336. DOI: https://doi.org/10.1038/s41598....
36.
Singh A.K., Sreenivasu S., Mahalaxmi U.S., Sharma H., Patil D.D., Asenso E. 2022. Hybrid feature-based disease detection in plant leaf using convolutional neural network, Bayesian Optimized SVM, and random forest classifier. Journal of Food Quality. 2845320: 16. DOI: https://doi.org/10.1155/2022/2....
37.
Singh V., Misra A.K. 2017. Detection of plant leaf diseases using image segmentation and soft computing techniques, Information Processing in Agriculture 4 (1): 41–49. DOI: https://doi.org/10.1016/j.inpa....
38.
Witten I.H., Frank E., Hall M. A., Pal C.J. 2016. Data Mining, Practical Machine Learning Tools and Techniques. 4th ed. Morgan Kaufmann Publishers Inc., San Francisco, CA, USA.
39.
Yogeshwari M., Thailambal G. 2020. Automatic Segmentation of Plant Leaf Disease Using Improved Fast Fuzzy C Means Clustering and Adaptive Otsu Thresholding (IFFCM-AO) Algorithm. European Journal of Molecular & Clinical Medicine 7 (3): 5447–5462.
40.
Zeng Y., Zhao Y., Yu Y., Tang Y., Tang Y. 2021. IOP Conference Series: Earth and Environmental Science 792 012001. DOI: https//doi.org/10.1088/1755-1315/792/1/012001.
